Seaborn简介 定义 Seaborn是一个基于matplotlib且数据结构与pandas统一的统计图制作库。Seaborn框架旨在以数据可视化为中心来挖掘与理解数据。
优点 pip命令安装 pip install matplotlib pip install seaborn
从github安装 pip install git+https://github.com/mwaskom/seaborn.git
流程 导入绘图模块 mport matplotlib.pyplot as plt import seaborn as sns
提供显示条件 %matplotlib inline #在Jupyter中正常显示图形
导入数据 #Seaborn内置数据集导入 dataset = sns.load_dataset('dataset' ) #外置数据集导入(以csv格式为例) dataset = pd.read_csv('dataset.csv' )
设置画布 #设置一块大小为(12,6)的画布 plt.figure(figsize=(12, 6))
输出图形 #整体图形背景样式,共5种:"white", "dark", "whitegrid", "darkgrid", "ticks" sns.set_style('white' ) #以条形图为例输出图形 sns.barplot(x=x,y=y,data=dataset,...) '' ' barplot()括号里的是需要设置的具体参数, 涉及到数据、颜色、坐标轴、以及具体图形的一些控制变量, 基本的一些参数包括' x'、' y'、' data',分别表示x轴,y轴, 以及选择的数据集。 ' ''
保存图形
#将画布保存为png、jpg、svg等格式图片 plt.savefig('jg.png' )
实战 #数据准备 df = pd.read_csv('./cook.csv' ) #读取数据集(「菜J学Python」公众号后台回复cook获取) df['难度' ] = df['用料数' ].apply(lambda x:'简单' if x<5 else ('一般' if x<15 else '较难' )) #增加难度字段 df = df[['菜谱' ,'用料' ,'用料数' ,'难度' ,'菜系' ,'评分' ,'用户' ]] #选择需要的列 df.sample(5) #查看数据集的随机5行数据
#导入相关包 import numpy as np import pandas as pd import matplotlib.pyplot as plt import matplotlib as mpl import seaborn as sns %matplotlib inline plt.rcParams['font.sans-serif' ] = ['SimHei' ] # 设置加载的字体名 plt.rcParams['axes.unicode_minus' ] = False # 解决保存图像是负号'-'显示为方块的问题 sns.set_style('white' ) #设置图形背景样式为white
直方图 #语法 '' ' seaborn.distplot(a, bins=None, hist=True, kde=True, rug=False, fit=None, hist_kws=None, kde_kws=None, rug_kws=None, fit_kws=None, color=None, vertical=False, norm_hist=False, axlabel=None, label=None, ax=None) ' '' #distplot()输出直方图,默认拟合出密度曲线 plt.figure(figsize=(10, 6)) #设置画布大小 rate = df['评分' ] sns.distplot(rate,color="salmon" ,bins=20) #参数color样式为salmon,bins参数设定数据片段的数量
#kde参数设为False,可去掉拟合的密度曲线 plt.figure(figsize=(10, 6)) sns.distplot(rate,kde=False,color="salmon" ,bins=20)
#设置rug参数,可添加观测数值的边际毛毯 fig,axes=plt.subplots(1,2,figsize=(10,6)) #为方便对比,创建一个1行2列的画布,figsize设置画布大小 sns.distplot(rate,color="salmon" ,bins=10,ax=axes[0]) #axes[0]表示第一张图(左图) sns.distplot(rate,color="green" ,bins=10,rug=True,ax=axes[1]) #axes[1]表示第一张图(右图)
#多个参数可通过字典传递 fig,axes=plt.subplots(1,2,figsize=(10,6)) sns.distplot(rate,color="salmon"
,bins=20,rug=True,ax=axes[0]) sns.distplot(rate,rug=True, hist_kws={'color' :'g' ,'label' :'直方图' }, kde_kws={'color' :'b' ,'label' :'密度曲线' }, bins=20, ax=axes[1])
散点图 常规散点图:scatterplot #语法 '' ' seaborn.scatterplot(x=None, y=None, hue=None, style=None, size=None, data=None, palette=None, hue_order=None, hue_norm=None, sizes=None, size_order=None, size_norm=None, markers=True, style_order=None, x_bins=None, y_bins=None, units=None, estimator=None, ci=95, n_boot=1000, alpha=' auto', x_jitter=None, y_jitter=None, legend=' brief', ax=None, **kwargs) ' '' fig,axes=plt.subplots(1,2,figsize=(10,6)) #hue参数,对数据进行细分 sns.scatterplot(x="用料数" , y="评分" ,hue="难度" ,data=df,ax=axes[0]) #style参数通过不同的颜色和标记显示分组变量 sns.scatterplot(x="用料数" , y="评分" ,hue="难度" ,style='难度' ,data=df,ax=axes[1])
分簇散点图:stripplot #语法 '' ' seaborn.stripplot(x=None, y=None, hue=None, data=None, order=None, hue_order=None, jitter=True, dodge=False, orient=None, color=None, palette=None, size=5, edgecolor=' gray', linewidth=0, ax=None, **kwargs) ' '' #设置jitter参数控制抖动的大小 plt.figure(figsize=(10, 6)) sns.stripplot(x="菜系" , y="评分" ,hue="难度" ,jitter=1,data=df)
分类散点图:swarmplot #绘制分类散点图(带分布属性) #语法 '' ' seaborn.swarmplot(x=None, y=None, hue=None, data=None, order=None, hue_order=None, dodge=False, orient=None, color=None, palette=None, size=5, edgecolor=' gray', linewidth=0, ax=None, **kwargs) ' '' plt.figure(figsize=(10, 6)) sns.swarmplot(x="菜系" , y="评分" ,hue="难度" ,data=df)
条形图 常规条形图:barplot #语法 '' ' seaborn.barplot(x=None, y=None, hue=None, data=None, order=None, hue_order=None,ci=95, n_boot=1000, units=None, orient=None, color=None, palette=None, saturation=0.75, errcolor=' .26', errwidth=None, capsize=None, ax=None, estimator=,**kwargs) ' ''
#barplot()默认展示的是某种变量分布的平均值(可通过修改estimator参数为max、min、median等) # from numpy import median fig,axes=plt.subplots(1,2,figsize=(10,6)) sns.barplot(x='菜系' ,y='评分' ,color="r" ,data=df,ax=axes[0]) sns.barplot(x='菜系' ,y='评分' ,color="salmon" ,data=df,estimator=min,ax=axes[1])
fig,axes=plt.subplots(1,2,figsize=(10,6)) #设置hue参数,对x轴的数据进行细分 sns.barplot(x='菜系' ,y='评分' ,color="salmon" ,hue='难度' ,data=df,ax=axes[0]) #调换x和y的顺序,可将纵向条形图转为水平条形图 sns.barplot(x='评分' ,y='菜系' ,color="salmon" ,hue='难度' ,data=df,ax=axes[1])
计数条形图:countplot #语法'''seaborn.countplot(x=None, y=None, hue=None, data=None, order=None,hue_order=None, orient=None, color=None, palette=None, saturation=0.75, dodge=True, ax=None, **kwargs)'''fig,axes=plt.subplots(1,2,figsize=(10,6))#选定某个字段,countplot()会自动统计该字段下各类别的数目sns.countplot(x='菜系',color="salmon",data=df,ax=axes[0])#同样可以加入hue参数sns.countplot(x='菜系',color="salmon",hue='难度',data=df,ax=axes[1])
折线图 #语法 '' ' seaborn.lineplot(x=None, y=None, hue=None, size=None, style=None, data=None, palette=None, hue_order=None, hue_norm=None, sizes=None, size_order=None, size_norm=None, dashes=True, markers=None, style_order=None, units=None, estimator=' mean', ci=95, n_boot=1000, sort=True, err_style=' band', err_kws=None, legend=' brief', ax=None, **kwargs) ' '' fig,axes=plt.subplots(1,2,figsize=(10,6)) #默认折线图有聚合 sns.lineplot(x="用料数" , y="评分" , hue="菜系" ,data=df,ax=axes[0]) #estimator参数设置为None可取消聚合 sns.lineplot(x="用料数" , y="评分" , hue="菜系" ,estimator=None,data=df,ax=axes[1])
箱图 箱线图:boxplot #语法 '' ' seaborn.boxplot(x=None, y=None, hue=None, data=None, order=None, hue_order=None, orient=None, color=None, palette=None, saturation=0.75, width=0.8, dodge=True, fliersize=5, linewidth=None, whis=1.5, notch=False, ax=None, **kwargs) ' '' fig,axes=plt.subplots(1,2,figsize=(10,6)) sns.boxplot(x='菜系' ,y='评分' ,hue='难度' ,data=df,ax=axes[0]) #调节order和hue_order参数,可以控制x轴展示的顺序,linewidth调节线宽 sns.boxplot(x='菜系' ,y='评分' ,hue='难度' ,data=df,color="salmon" ,linewidth=1, order=['清真菜' ,'粤菜' ,'东北菜' ,'鲁菜' ,'浙菜' ,'湖北菜' ,'川菜' ],
hue_order=['简单' ,'一般' ,'较难' ],ax=axes[1])
箱型图:boxenplot #语法 '' ' seaborn.boxenplot(x=None, y=None, hue=None, data=None, order=None, hue_order=None, orient=None, color=None, palette=None, saturation=0.75, width=0.8, dodge=True, k_depth=' proportion', linewidth=None, scale=' exponential', outlier_prop=None, ax=None, **kwargs) ' '' fig,axes=plt.subplots(1,2,figsize=(10,6)) sns.boxenplot(x='菜系' ,y='评分' ,hue='难度' ,data=df,color="salmon" ,ax=axes[0]) #palette参数可设置调色板 sns.boxenplot(x='菜系' ,y='评分' ,hue='难度' ,data=df, palette="Set2" ,ax=axes[1])
小提琴图 #语法 '' ' seaborn.violinplot(x=None, y=None, hue=None, data=None, order=None, hue_order=None, bw=' scott', cut=2, scale=' area', scale_hue=True, gridsize=100, width=0.8, inner=' box', split=False, dodge=True, orient=None, linewidth=None, color=None, palette=None, saturation=0.75, ax=None, **kwargs) ' '' fig,axes=plt.subplots(1,2,figsize=(10,6)) sns.violinplot(x='菜系' ,y='评分' ,data=df, color="salmon" ,linewidth=1,ax=axes[0]) #inner参数可在小提琴内部添加图形,palette设置颜色渐变 sns.violinplot(x='菜系' ,y='评分' ,data=df,palette=sns.color_palette('Greens' ),inner='stick' ,ax=axes[1])
回归图 regplot '' ' seaborn.regplot(x, y, data=None, x_estimator=None, x_bins=None, x_ci=' ci', scatter=True, fit_reg=True, ci=95, n_boot=1000, units=None, order=1, logistic=False, lowess=False, robust=False, logx=False, x_partial=None, y_partial=None, truncate=False, dropna=True, x_jitter=None, y_jitter=None, label=None, color=None, marker=' o', scatter_kws=None, line_kws=None, ax=None) ' '' fig,axes=plt.subplots(1,2,figsize=(10,6)) #marker参数可设置数据点的形状 sns.regplot(x='用料数' ,y='评分' ,data=df,color='r' ,marker='+' ,ax=axes[0]) #ci参数设置为None可去除直线附近阴影(置信区间) sns.regplot(x='用料数' ,y='评分' ,data=df,ci=None,color='g' ,marker='*' ,ax=axes[1])
lmplot #语法 '' ' seaborn.lmplot(x, y, data, hue=None, col=None, row=None, palette=None,
col_wrap=None, height=5, aspect=1, markers=' o', sharex=True, sharey=True, hue_order=None, col_order=None, row_order=None, legend=True, legend_out=True, x_estimator=None, x_bins=None, x_ci=' ci', scatter=True, fit_reg=True, ci=95, n_boot=1000, units=None, order=1, logistic=False, lowess=False, robust=False, logx=False, x_partial=None, y_partial=None, truncate=False, x_jitter=None, y_jitter=None, scatter_kws=None, line_kws=None, size=None) ' '' #lmplot()可以设置hue,进行多个类别的显示,而regplot()是不支持的 sns.lmplot(x='用料数' ,y='评分' ,hue='难度' ,data=df, palette=sns.color_palette('Reds' ),ci=None,markers=['*' ,'o' ,'+' ])
热力图 #语法 '' ' seaborn.heatmap(data, vmin=None, vmax=None, cmap=None, center=None, robust=False, annot=None, fmt=' .2g', annot_kws=None, linewidths=0, linecolor=' white', cbar=True, cbar_kws=None, cbar_ax=None, square=False, xticklabels=' auto', yticklabels=' auto', mask=None, ax=None, **kwargs) ' '' fig,axes=plt.subplots(1,2,figsize=(10,6)) h=pd.pivot_table(df,index=['菜系' ],columns=['难度' ],values=['评分' ],aggfunc=np.mean) sns.heatmap(h,ax=axes[0]) #annot参数设置为True可显示数字,cmap参数可设置热力图调色板 cmap = sns.diverging_palette(200,20,sep=20,as_cmap=True) sns.heatmap(h,annot=True,cmap=cmap,ax=axes[1]) #保存图形 plt.savefig('jg.png' )
