nginx+varnish+angular universal实现服务端页面渲染缓存

bugDeveloper • 5 年前 • 307 次点击

nginx+varnish+angular universal实现服务端页面渲染缓存

项目使用angular universal实现服务端渲染,为了减轻服务器的压力,需要将用户频繁访问的页面进行缓存,这样就不必每次都去渲染相同的页面(例如首页),angular universal在features中有提到考虑加入缓存,但就目前来说,varnish是个不错的选择,但是varnish不支持https,所以还需要用nginx进行端口的转发

总的思路

  1. nginx监听80端口将http重定向到https
  2. nginx监听443端口,并将443端口的请求转发到8080端口
  3. varnish监听8080端口的请求,如果与缓存中的页面匹配,则返回页面,如果没有匹配的页面,则请求pm2启动的服务

总的流程

  1. 安装与配置nginx
  2. 安装SSL证书,nginx配置SSL
  3. 安装与启动PM2
  4. 安装与配置varnish

Nginx的安装与配置

  1. 安装nginx

    yum install nginx

  2. 配置nginx以安装SSL证书 ( 使用varnish时,不需要nginx监听80端口,nginx监听443端口然后转发到80端口即可 )

    //找到nginx配置文件所在目录
    Linux code: nginx -t

    //打开nginx.conf文件配置一个server
    server {
    	listen       80;  //监听的端口
    	server_name  panoramic.laipaiya.com; //域名
    	root         /usr/local/web/Panoramic; //文件路径
    	location / {
    		index  index.html; //主页
    	}
    }

    //检查配置是否有误
    Linux code: nginx -t

  3. 开启gzip

    //在config文件中加入以下代码
    gzip on;
    gzip_min_length 1k;
    gzip_buffers 4 16k;
    gzip_comp_level 5;
    gzip_types text/plain application/x-javascript text/css application/xml text/javascript application/x-httpd-php;

  4. 启动nginx

    service nginx start/restart/reload(修改配置后无需重启,reload即可)/stop


Certbot证书配置

  1. 下载certbot

    //安装git
    yum install git

    git clone https://github.com/certbot/certbot
    cd certbot

  2. 安装证书

    ./certbot-auto certonly --webroot --agree-tos -v -t --email 邮箱地址 -w 网站根目录 -d 网站域名

    //安装成功后会看到这样的信息,在配置nginx时会用上
    Congratulations! Your certificate and chain have been saved at:
       /etc/letsencrypt/live/beta.laipaiya.com/fullchain.pem
       Your key file has been saved at:
       /etc/letsencrypt/live/beta.laipaiya.com/privkey.pem
       Your cert will expire on 2018-06-28. To obtain a new or tweaked
       version of this certificate in the future, simply run certbot-auto
       again. To non-interactively renew *all* of your certificates, run
       "certbot-auto renew"

  3. 证书的有效期为3个月,需要更新证书

    ./certbot-auto renew


Nginx配置SSL

  1. 在nginx.conf文件中,新加一个server,将443端口转发到80端口

    server {
        listen 443 ssl;
        server_name beta.laipaiya.com;
        //将ssl证书生成后的pem路径复制到ssl_certificate、ssl_certificate_key
        ssl_certificate /etc/letsencrypt/live/beta.website.com/fullchain.pem;
        ssl_certificate_key /etc/letsencrypt/live/beta.website.com/privkey.pem;
        location / {
            proxy_pass http://127.0.0.1:80;
            proxy_set_header X-Real-IP  $remote_addr;
            proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
            proxy_set_header X-Forwarded-Proto https;
            proxy_set_header X-Forwarded-Port 443;
            proxy_set_header Host $host;
        }
    }


PM2

  1. 安装pm2

    npm install pm2 -g

  2. 启动pm2

    //启动参数
    --watch 监视项目,如有更改自动重启
    -n 为项目命名

    pm2 start /usr/local/web/PCbeta/server.js --watch -n PC_SSR_beta

  3. pm2命令

    pm2 list  //列出所有应用
    pm2 stop all  //停止所有应用
    pm2 stop name|app_id  //停止指定的应用
    pm2 restart name|app_id  //重启指定的应用
    pm2 logs  //查看日志

  4. 对于angular universal应用,需要将生成的dist目录、dist-server目录、server.js一并复制到项目文件夹中

Varnish

  1. 修改varnish配置

    //找到varnish所在目录
    Linux code: whereis varnish

    //打开 varnish.params,修改varnish监听的端口为80,接收该端口的http请求
    VARNISH_LISTEN_PORT=80

    //打开 default.vcl
    //修改指向服务器的地址和端口(pm2运行的端口)
    backend pc {
        .host = "127.0.0.1"; //指向本地服务器
        .port = "4000";  //监听8080端口运行的程序
    }

    //可同时存在多个backend,实现多域名同时使用varnish缓存
    backend pcbeta {
        .host = "127.0.0.1";
        .port = "4001";
    }
    //对不需要使用cookie的页面屏蔽cookie检查,提高命中率,cookie不同varnish会认为是不同的页面,这里只对包含home路径的页面进行检查

    sub vcl_recv{
        if (!(req.url ~ "^/home/")) {
        	unset req.http.Cookie;
        }
    }

  2. varnish命令

    //启动
    service varnish start

    //停止
    service varnish stop

    //查看统计日志

    varnishtop:读取共享内存中的日志,同时会显示一个不断更新的列表

    varnishhist:读取varnishd共享内存日志,同时生成一个连续不断更新的柱状图显示最后 N 个请求的分布。

    N的值和垂直比例尺显示在左上角的位置。水平刻度是对数的,命中标记是“|”,未命中标记是“#”。

    varnishstat:统计未命中、命中、存储信息、线程创建、删除对象等
