数学推导+纯Python实现机器学习算法：XGBoost

class XGBoostTree(Tree):    # 结点分裂    def _split



(self, y):        col = int(np.shape(y)[1]/2)        y, y_pred = y[:, :col], y[:, col:]        return y, y_pred
    # 信息增益计算公式    def _gain(self, y, y_pred):        Gradient = np.power((y * self.loss.gradient(y, y_pred)).sum(), 2)        Hessian = self.loss.hess(y, y_pred).sum()        return 0.5 * (Gradient / Hessian)
    # 树分裂增益计算    def _gain_by_taylor(self, y, y1, y2):        # 结点分裂        y, y_pred = self._split(y)        y1, y1_pred = self._split(y1)        y2, y2_pred = self._split(y2)
        true_gain = self._gain(y1, y1_pred)        false_gain = self._gain(y2, y2_pred)        gain = self._gain(y, y_pred)        return true_gain + false_gain - gain
    # 叶子结点最优权重    def _approximate_update(self, y):        # y split into y, y_pred        y, y_pred = self._split(y)        # Newton's Method        gradient = np.sum(y * self.loss.gradient(y, y_pred), axis=0)        hessian = np.sum(self.loss.hess(y, y_pred), axis=0)        update_approximation =  gradient / hessian
        return update_approximation
    # 树拟合方法    def fit(self, X, y):        self._impurity_calculation = self._gain_by_taylor        self._leaf_value_calculation = self._approximate_update        super(XGBoostTree, self).fit(X, y)

class XGBoost(object):
    def __init__(self, n_estimators=200, learning_rate=0.001, min_samples_split=2,                 min_impurity=1e-7, max_depth=2):        self.n_estimators = n_estimators            # Number of trees        self.learning_rate = learning_rate          # Step size for weight update        self.min_samples_split = min_samples_split  # The minimum n of sampels to justify split        self.min_impurity = min_impurity            # Minimum variance reduction to continue        self.max_depth = max_depth                  # Maximum depth for tree

        # 交叉熵损失        self.loss = LogisticLoss()
        # 初始化模型        self.estimators = []        # 前向分步训练        for _ in range(n_estimators):            tree = XGBoostTree(                    min_samples_split=self



.min_samples_split,                    min_impurity=min_impurity,                    max_depth=self.max_depth,                    loss=self.loss)
            self.estimators.append(tree)
    def fit(self, X, y):        y = to_categorical(y)
        y_pred = np.zeros(np.shape(y))        for i in range(self.n_estimators):            tree = self.trees[i]            y_and_pred = np.concatenate((y, y_pred), axis=1)            tree.fit(X, y_and_pred)            update_pred = tree.predict(X)            y_pred -= np.multiply(self.learning_rate, update_pred)
    def predict(self, X):        y_pred = None        # 预测        for tree in self.estimators:            update_pred = tree.predict(X)            if y_pred is None:                y_pred = np.zeros_like(update_pred)            y_pred -= np.multiply(self.learning_rate, update_pred)
        y_pred = np.exp(y_pred) / np.sum(np.exp(y_pred), axis=1, keepdims=True)        # 将概率预测转换为标签        y_pred = np.argmax(y_pred, axis=1)        return y_pred

from sklearn import datasetsdata = datasets.load_iris()X = data.datay = data.target
X_train, X_test, y_train, y_test = train_test_split(X, y, test_size=0.4, seed=2)
clf = XGBoost()clf.fit(X_train, y_train)y_pred = clf.predict(X_test)
accuracy = accuracy_score(y_test, y_pred)print ("Accuracy:", accuracy)

Accuracy: 0.9666666666666667

pip install xgboost

import xgboost as xgbfrom xgboost import plot_importancefrom matplotlib import pyplot as plt
# 设置模型参数params = {    'booster': 'gbtree',    'objective': 'multi:softmax',       'num_class': 3,         'gamma': 0.1,    'max_depth': 2,    'lambda': 2,    'subsample': 0.7,    'colsample_bytree': 0.7,    'min_child_weight': 3,    'silent': 1,    'eta': 0.001,    'seed': 1000,    'nthread': 4,}
plst = params.items()




dtrain = xgb.DMatrix(X_train, y_train)num_rounds = 200model = xgb.train(plst, dtrain, num_rounds)
# 对测试集进行预测dtest = xgb.DMatrix(X_test)y_pred = model.predict(dtest)
# 计算准确率accuracy = accuracy_score(y_test, y_pred)print ("Accuracy:", accuracy)# 绘制特征重要性plot_importance(model)plt.show();

Accuracy: 0.9166666666666666
